PP PE PMMA PET Recycling granulation Machinery pelletizing machine.
Plastic Recycling Machine.
PP PE Film Two Steps Pelletizer Production Line Machine.
This pelletizing extruder has the special screw design and
different configuration, it is suitable for the recycling and
pelletizing of raw materials such as PP, PE, PET, PS, ABS, PA, PVC,
PC, POM, EVA, PMMA and the pelletizing of the raw materials with
different colors. The gearbox is high torque designed which attains
the functions of low noise and stable operation. The surface of the
screw and barrel has been special treated so that the screw and
barrel are wearable, they can have a very good plastification and
mixing effect and the production capacity is high. The extruder has
the vacuum vented design which can exhaust the vapor or gas during
the production, so that the output can be more stable and the
pellets are more dense.
| Model | Screw dia.
(mm) | L/D | Screw speed max.
(rpm) | Main motor power
(kw) | Output (kg/h) |
| XSSP45 | 45 | 25-36 | 20-120 | 5.5-11 | 18-40 |
| XSSP65 | 65 | 25-36 | 20-120 | 15-37 | 40-90 |
| XSSP90 | 90 | 25-36 | 20-95 | 37-75 | 100-250 |
| XSSP120 | 120 | 25-36 | 20-80 | 55-110 | 250-380 |
| XSSP150 | 150 | 25-36 | 20-80 | 110-160 | 300-450 |
| XSSP180 | 180 | 25-36 | 20-80 | 180-250 | 400-650 |
| Model | Screw dia.
(mm) | L/D | Screw speed max.
(rpm) | Main motor power
(kw) | Output (kg/h) |
| SJ-45 | 45 | 25-36 | 20-120 | 5.5-11 | 18-40 |
| SJ-65 | 65 | 25-36 | 20-120 | 15-37 | 40-90 |
| SJ-90 | 90 | 25-36 | 20-95 | 37-75 | 100-250 |
| SJ-120 | 120 | 25-36 | 20-80 | 55-110 | 250-380 |
| SJ-150 | 150 | 25-36 | 20-80 | 110-160 | 300-450 |
| SJ-180 | 180 | 25-36 | 20-80 | 180-250 | 400-650 |
